Guide Thermal Monocular - TE211 Mini
TE 211M Handheld Thermal Imaging Monocular
The TE 211M is a lightweight, compact, and powerful thermal imaging monocular, perfect for night vision, outdoor exploration, and hunting. Equipped with a 256×192@12μm infrared sensor and a 10mm F1.0 lens, it delivers a detection range of up to 550 yards. Its 1.43” AMOLED full-color touchscreen provides crystal-clear infrared images without eye strain, ensuring a comfortable viewing experience.
Key Features:
✔ Ultra-Lightweight & Portable – Weighs just 205g, easy to carry anywhere.
✔ Clear & Comfortable Viewing – 1.43” AMOLED touchscreen for strain-free observation.
✔ Long Battery Life – Up to 6 hours of use, with 20W quick charging (1 hour use from 10-minute charge).
✔ Seamless Operation – One-button control and focus-free lens for hassle-free use.
✔ Advanced Imaging – NETD 30mK, 50Hz frame rate, and multiple color palettes for high-quality thermal detection.
✔ Audio & Video Recording – 16GB storage, Wi-Fi/Bluetooth connectivity, and synchronized audio recording.
✔ Durable & Weatherproof – IP67-rated, built for rugged outdoor conditions.
Technical Specifications:
Sensor: 256×192@12μm Uncooled VOx Infrared Detector (8-14μm)
Lens: 10mm F1.0, Focus-Free
Magnification: 1.2x ~ 4.8x
Detection Range: Up to 550 yards (500m)
Display: 1.43” AMOLED Touchscreen (466×466)
Color Palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
Connectivity: Wi-Fi (2.4G & 5G), Bluetooth, USB-C (Charging & Data)
Recording: Photo/Video with Audio Recording, 16GB Storage
Battery Life: 6 hours, 20W fast charging support
Durability: IP67-rated, operates in temperatures from -20°C to 50°C (-4°F to 122°F)
What’s in the Box?
✔ TE 211M Device
✔ Lens Cover
✔ Wrist Strap
✔ USB-A to USB-C Cable
✔ Quick Use Guide & Safety Information Manual
✔ Warranty Card
Optional Accessories: Bluetooth Remote Control, Quick Charging Adapter, USB-C to USB-C Cable.
The TE 211M is the ultimate thermal monocular for adventurers, hunters, and security professionals, delivering high-performance night vision in a compact and easy-to-use design.
