Guide Thermal Monocular - TE421
TE 421 Handheld Thermal Imaging Monocular
The TE 421 is a high-performance, lightweight thermal imaging monocular designed for night vision, hunting, and outdoor exploration. Equipped with a 400×300@12μm infrared sensor and a 25mm F1.0 lens, it offers an impressive detection range of up to 1400 yards. Its 0.32” AMOLED 800×600 display delivers sharp, full-color thermal imaging, ensuring clear viewing without eye strain.
Key Features:
✔ Sharp & Lightweight – 295g, making it highly portable.
✔ Superior Detection Range – Up to 1400 yards (1300m) for long-distance observation.
✔ High-Resolution Display – 0.32” AMOLED 800×600 for crisp infrared imagery.
✔ Extended Battery Life – Up to 5 hours, with 20W fast charging (1-hour use from a 10-minute charge).
✔ Manual Focus – Ensures precise image clarity at varying distances.
✔ Advanced Imaging – NETD 25mK, 50Hz frame rate, and multiple color palettes for enhanced thermal detection.
✔ Audio & Video Recording – 16GB storage, Wi-Fi/Bluetooth connectivity, and synchronized audio recording.
✔ Durable & Weatherproof – IP67-rated, built to withstand extreme environments.
Technical Specifications:
Sensor: 400×300@12μm Uncooled VOx Infrared Detector (8-14μm)
Lens: 25mm F1.0, Manual Focus
Magnification: 1.9x ~ 7.6x
Detection Range: Up to 1400 yards (1300m)
Field of View (FOV): 11°×8.2° (19×14 m @ 100m)
Display: 0.32” AMOLED 800×600
Color Palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
Eyepiece: 25mm Eye Relief, -5 to +5 Diopter, 14x Digital Zoom
Connectivity: Wi-Fi (2.4G & 5G), Bluetooth, USB Type-C (Charging & Data)
Recording: Photo/Video with Audio Recording, 16GB Storage
Battery Life: 5 hours, 20W fast charging support
Durability: IP67-rated, operates in temperatures from -20°C to 50°C (-4°F to 122°F)
What’s in the Box?
✔ TE 421 Device
✔ Lens Cover & Eye Mask
✔ Wrist Strap
✔ Quick Charging Adapter
✔ USB Type-C Cable
✔ Quick Use Guide & Safety Information Manual
✔ Warranty Card
Optional Accessories: Bluetooth Remote Control.
The TE 421 is a top-tier thermal monocular for professionals and outdoor enthusiasts, combining exceptional detection range, precision imaging, and user-friendly controls for an unparalleled night vision experience.
